Varieties |
Descriptions |
Tekcon P/N |
Pictures |
Drawings |
USB 2.0 B Type R/A |
Receptacle G/F Black Shell Tail Length 3.3mm |
5411-12-010-A2 |
 |
 |
USB 3.0 A Type Upright |
Receptacle Dip Type Shell: w/ Folder Straight and Harpoon Tail |
5405-0B8-011-01 |
/s5405-0B8-011-01.jpg) |
 |
USB 3.0 A Type Vertical |
Receptacle Dip Type Shell w/ Kinked Tail H: 15mm |
5405-015-011-01 |
 |
 |
USB 3.0 A Type Normal |
R/A Receptacle Dip Type Shell: w/ Folder Kinked Tail |
5405-311-021-H1 |
/s5405-X11-0XX-XX.jpg) |
 |
USB 3.0 A Type Reverse |
Receptacle Dip Type Black Shell: w/o Folder Straight Tail |
5405-S09-032-H1 |
/s5405-S09-032-H1.jpg) |
 |
USB 3.0 A Type Dual Port |
R/A Receptacle Dip Type Shell w/o Spring Kinked Tail |
5406-011-031-01 |
 |
 |
USB 3.0 A Type Cable End |
Plug Sold Type L: 36.3mm |
5418-313-A22-01 |
 |
 |
Pin Header |
R/A 2.54mm Double Row 4PIN |
1136-1A04-04R-F |
 |
 |
D-SUB R/A Type |
9Pin Receptacle Footprint 0.318" |
1210-004-09S-AAA |
 |
 |
D-SUB R/A Type |
15Pin Receptacle Footprint 0.318" |
1210-004-15S-AAE |
 |
 |
D-SUB VGA R/A |
15 Pin Receptacle Footprint 5.0mm Receptacle Blue Spacer: Open Type |
1216-004-15S-AAF |
 |
 |
D-SUB VGA R/A |
15Pin Receptacle Footprint 5.0mm Spacer: Close Type |
1216-00D-15S-2EF |
 |
 |
D-SUB VGA R/A |
15Pin Receptacle Footprint 5mm Matt Tin on solder Tail Spacer: Close Type |
1216-00D-15S-2EJ |
 |
 |
D-SUB R/A Type |
VGA 15Pin Receptacle Footprint 5.0mm Black Spacer: Open Type |
1216-00D-15S-3E2 |
 |
 |
D-SUB VGA Vertical |
Male 9Pin H: 10.5mm |
1221-004-09P-LAU |
 |
 |
D-SUB Vertical |
15Pin Receptacle Blue H: 10.5mm |
1226-004-15S-LAF |
 |
 |
D-SUB Vertical |
15Pin Receptacle Blue H: 10.5mm Halogen Free |
1226-004-15S-LHF |
 |
 |
D-SUB VGA Vertical |
15Pin Receptacle w/ screw Black H: 13mm |
1229-01H-15F-ZAD |
 |
 |
D-SUB VGA Vertical |
15Pin Receptacle Blue H: 15mm |
1229-00H-15S-HAF |
 |
 |
DVI R/A Type |
DVI-I Receptacle 29PIN |
1241-040-105-3NH |
 |
 |
DVI R/A Type |
DVI-D Receptacle 24PIN w/ Shielding |
1241-040-1F4-3NH |
 |
 |
DVI R/A Type |
DVI-D Receptacle 24PIN w/ Shielding Halogen Free |
1241-080-0F4-3P |
 |
 |
DVI R/A Type |
DVI-I Receptacle 29PIN 3u" Gold |
1241-440-104-3B |
 |
 |
DVI R/A Type |
DVI-D Receptacle 24PIN |
1241-440-154-3B |
 |
 |
HDMI R/A |
Receptacle 19Pin w/o Flange Matt Tin Plating on Solder Tail |
5300-519-4C4-H7 |
 |
 |
HDMI R/A |
Receptacle 19Pin w/o Flange Bright Tin Plating on Solder Tail |
5300-519-3C1-E7 |
 |
 |
MS/MS Duo Card Conn. |
Reverse Normal Type 15u" Gold on Contact Area |
4841-501-100-H1 |
 |
 |
MS/MS Duo Card Conn. |
Reverse Normal Type 3u" Gold on Contact Area |
4841-401-300-51 |
 |
 |
